Quick Details
Application: HDPE winding pipe
Plastic Processed: PE, PP
Screw Design: Single-screw
Automatic Grade: Automatic
Place of Origin: Jiangsu China (Mainland)
Brand Name: Sansu_PE winding pipe extrusion line
Voltage: 380V/50Hz, 440V/60HZ, 220V/60HZ, 415V/50HZ,
Power(W): 110KW
Dimension(L*W*H): 28M*2.5M*3.5M
Weight: 8-20T
Certification: CE/ISO/BV
After-sales Service Provided: Engineers available to service machinery overseas
Lifetime: More than 10 years
Guarantee time: 12months after machine installation in customer’s factory
Pipe range: 200-3000mm
Stiffness steel: SN4, SN8,
Inverter: ABB
Temperature controller: RKC
Low voltage unit: DELEX
Contactor: Siemens
Usage of PE winding pipe:
* Municipal Engineering: used for building rainwater pipes, underground drainage, sewage, ventilation tubes.
* Communication pipe: rail, road communication, communication cable, fiber optic cable protection tubes.
Industry: Widely used in industrial fields sewage pipes.
* Agricultural Engineering: used for farmland, orchards, tea plantations and forest irrigation.
* Road works: as railway, highway infiltration, drainage.
* Mine: for mine ventilation, air supply, drainage, mud tubes.
* Sports venue: as golf courses, soccer and other sports venues seepage drains.
* Port, dock project: large airport, port, pier drainage, sewage and so on.
* Landfill sewage collection pipe. Sewage treatment system
* Water storage system. Slow flow for interception storage system.
* Seawater pipelines.
Advantage of PE winding pipe:
* good joint welding, no leakage.
* corrosion resistance, long life. pipeline life expectancy of 100 years.
* saving shipping cost. In case of large-scale pipeline projects, the device can be moved to the on-site production, that can save transportation costs.
* big length of pipe. In the pipe production, both HDPE profile can be welded continuously, so pipe can be very long, it reduces cost with reduction of pipe connection, further eliminates leakage.
diameter adjustable. The same strip can produce different diameter pipe, according to the request of pipe stiffness. therefore, it is flexible to arrange the production.
The Main specification of PE winding pipe extrusion line
|
pipe diameter |
200-1200mm |
800-2000mm |
1200-3000mm |
|
profile extruder model |
SJ75 |
SJ75 |
SJ90 |
|
extruder motor |
37KW |
55KW |
75KW |
|
extruder heating power |
18KW |
24KW |
36KW |
|
profile mould |
4 sets |
5 sets |
6 sets |
|
mould material |
3Cr17 |
||
|
vacuum table dimension |
4800(L)*1100(W) |
6000(L)*1200(W) |
6000(L)*1300(W) |
|
vacuum pump |
5.5KW*２ |
5.5KW*3 |
5.5KW*4 |
|
water pump |
2.2KW*1 |
3KW*1 |
3KW*1 |
|
dry blower |
750W |
750W |
750W |
|
effective haul off length |
1800mm |
2000mm |
2500mm |
|
haul of motor |
1.5KW*2 |
1.5KW*2 |
2.2KW*2 |
|
coiler |
15KN |
||
|
dimension of winding |
6*2.2*4.5m |
6.8*2.8*5m |
7.5*3.6*6.5m |
|
side extruder model |
SJ45 |
||
|
extruder motor |
15KW |
||
|
extruder heating power |
12KW |
||
|
top extruder model |
SJ65 |
SJ75 |
SJ90 |
|
extruder motor |
37KW |
45KW |
75KW |
|
extruder heating power |
22KW |
28KW |
42KW |
|
winding motor |
1５KW |
22KW |
30KW |
|
roller size |
66*1000mm |
90*1200mm |
110*1400mm |
|
length of pipe |
6-12m |
||
|
cutting disk |
Alloy disk |
||
|
cutting precision |
<10mm |
||
